Epower (10~200KVA) 3:3 Phase

  • Application
  • Features
  • Specifications



Application:
Small-medium computer data center, industrial process and other mission-critical equipment.





Features:

� Three phase in, three phase out
� Double conversion on line technology
� Static bypass
� Manual maintenance bypass
� Double CPU control
� LCD with control panel
� Remote management
� Parallel redundant
� Self diagnosis
� Low noise
� High efficiency cuts down your expense
� Wide input voltage range

Series Epower Series
Capacity 10KVA 15KVA 20KVA 30KVA 40KVA 60KVA 80KVA 100KVA 120KVA 160KVA 200KVA
Power 8KW 12KW 16KW 24KW 32KW 48KW 64KW 80KW 96KW 128KW 160KW
Power Factor 0.8
Input
Phase 3 phase 4 wire and ground
Voltage Range +/-20%
Frequency Range 45 � 65Hz
Rectifier 3 phase 6 pulses
Output
Phase 3 phase 4 wire and ground
Wave form Sine wave
Crest Factor 3:1
Rated voltage 380/400/415V optional
Phase voltage setting 200 - 244VAC   (control panel )
Transient response +/-5%, 10ms
Frequency 50 / 60 Hz
Frequency stability + / - 0.05%
Range of phase lock With synchronization:    +/-0.05%. Without synchronization: + /- 2% (settable +/-1% on the control panel)
Total harmonic distortion 3% ( linear load)
Short circuit current Short current for 0.1s (200% current)
Overload capacity 110% /125% /150% rated current 300 min/ 10min /1min
Battery
Battery Maintenance free lead-acid cell
DC Voltage                                                  384VDC                                   432VDC 480VDC
Bypass
Type Static state + manual maintenance bypass
Input Phase 3 phase 4 wire and ground
Input voltage range 15% - 25% (the front control panel selectable)
Input frequency range +/-1%   ~   +/- 5% the front control panel selectable
Transfer time Inverter / bypass transfer switch time(Overload): 0ms   inverter / bypass transfer switch time (fault inverter) 1ms
Overload capacity (10 min) 170% 180% 170% 170% 170% 140% 130% 125% 125% 125% 125%
System
Remote signaling Dry contact (battery low, battery discharging, bypass/ fault); output 12Vdc/80mA
Remote control EPO and bypass
Communication interface RS232 ( SNMP , modem optional )
Running temperature 0-40 degree Celsius
Relative Humidity Less than 95% (without condensing)
Altitude 1000m output nominal power (with increase of 100m, it will reduce output of 1%) max 4000m
Noise at 1 M less than 60 dB
Inverter Efficiency 92% 93%
Degree of protection IP20
Applicable Standards EN50091-1-EMC   EN50091-2liv.A
Optional Isolating transformer
Harmonic wave suppression filter
Parallel modules can be up to six
Net/Gross   weight (Kg) 223/280 260/317 260/317 336/393 351/408 497/574 556/633 756/856 901/1001 1300/1400 1350/1450
Unit Dimension(W×D×H) mm 555�725�1220 800�745�1400 1070�745�1400 1420�745�1810
Packing Dimension(W×D×H) mm 660�855�1425 880�945�1585 1254�875�1585 1520�880�2000
